Latestelectric Construction Vehicles
Company Advantages
· AILISHENG Construction Equipment electric construction vehicles has a design that is prevalent in the industry.
· Features of electric construction vehicles has brought brand favorability to AILISHENG Construction Equipment and its business.
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd can design and produce all kinds of special electric construction vehicles according to the requirements of customers.
Product features
● Four wheel drive, full power. The whole machine has compact structure and flexible operation. The structural parts of the whole machine are optimized, stable and reliable.
● Reliable battery, drive motor and electrical accessory system, advanced AC controller and CANbus data bus technology ensure the durability and long endurance of the equipment.
● The cover of the whole machine can be turned over to facilitate maintenance. The system maintenance items are simple and convenient, saving maintenance time and labor cost. Families can charge by themselves, which is convenient and safe to use.
● The operating device is designed by ergonomics, with comfortable operation and stable driving. The whole machine protection frame provides full safety protection for drivers.
● Pure electric system has the advantages of high efficiency, zero exhaust emission, low noise, environmental protection and energy saving. It is suitable for indoor and outdoor use with lower cost.
● A variety of accessories can be selected to meet the needs of various working conditions such as loading, forking, grass clamping, snow pushing, cleaning, drilling, hoisting and so on.
|
Model |
Fuel loader |
Electric Loader |
Cost comparison of 200 days per year |
||||
|
Country |
Diesel price |
Hourly fuel consumption |
Cost of working 8 hours per day |
Electricity price |
Hourly energy consumption |
Cost of working 8 hours per day |
|
|
Canada |
1.6 C$/L |
5L/h |
64 C$ |
0.06 C$/Kwh |
5Kwh/h |
2.4 C$ |
save 12320 C$ |
|
U.S.A |
0.66 $/L |
26.4 $ |
0.13 $/Kwh |
5.2 $ |
Save 4240 $ |
||
|
China |
6.7 RMB/L |
268 RMB |
0.50RMB/Kwh |
20 RMB |
Save 49600 RMB |
||
Main technical parameter
|
|
ALS3080EV |
|
Electric motor model |
5×PMSM |
|
Rated power |
5x12kW |
|
Maximum power |
5x12kW |
|
Maximum torque(PER MOTOR) |
160Nm |
|
Battery Pack |
40kwh |
|
Max. Speed (km/h) |
13 |
|
Tire (track) model |
10-16.5 |
|
Loading Capacity(kg) |
800 |
|
Bucket capacity(m3) |
0.4 |
|
Rated flow(L/min) |
62.5 |
|
hydraulic tank capacity(L) |
70 |
|
Weight with bucket(kg) |
2700 |
|
Height at Maximum Extension (mm) |
4270 |
|
Hinge Pin Height (mm) |
3080 |
|
Total Height (mm) |
2200 |
|
Height to bottom of bucket(mm) |
2913 |
|
Overall length without bucket ( mm ) |
2640 |
|
overall length with bucket(mm) |
3420 |
|
Dumping angle at maximum height(° ) |
40 |
|
Dumping height(mm) |
2380 |
|
Dumping reach(mm) |
700 |
|
Rollback at ground position(° ) |
30 |
|
Rollback fully raised at max height(° ) |
104 |
|
Wheelbase(mm) |
991 |
|
Ground clearance(mm) |
185 |
|
Angle of departure(°) |
20 |
|
Front turning radius without bucket(mm) |
1168 |
|
Front turning radius(mm) |
1958 |
|
Rear tuning radius(mm) |
1630 |
|
Rear length (mm) |
1108 |
|
Track width(mm) |
1450 |
|
Width (mm) |
1720 |
|
Bucket width (mm) |
1740 |
Company Features
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd takes superiority in the manufacturing of electric construction vehicles. We have already enhanced competence in today's fierce market competition.
· To be at the forward position in electric construction vehicles field, AILISHENG Construction Equipment has been applied the most advanced technology to make a difference.
· We always adhere to the principle of 'quality first'. Good quality products will help us win more customers. Hence, we will conduct specialized education and technical training to the workers, and work together to improve product quality.
Enterprise Advantages
AILISHENG Construction Equipment has a professional team with excellent business skills and strong comprehensive quality. We strive to achieve rapid development by giving full play to each member's potential.
provides customers with a full range of services to meet the individual needs of different customers.
With a focus on customers, our company always believes that integrity management brings mutual benefit. Based on the the core value of 'efficient, pragmatic, excellent, innovative', we insist on serving every customer wholeheartedly and creating effective value for customers with innovative products and services.
AILISHENG Construction Equipment was built in After years of experience in innovation, we have developed into a model enterprise with leading technology in the industry.
AILISHENG Construction Equipment's products have been sold to the domestic market and overseas markets such as Western Europe, Eastern Europe, North America, and South America. The sales scale and quantity rank top in the domestic industry.
