Product details of the electric construction machinery
Product Information
AILISHENG Construction Equipment electric construction machinery is manufactured by our adroit professionals using premium grade raw material and modern technology. The product has been approved by many international certifications. Known for its huge economic benefits, the product is highly regarded in the market.
Product features
● Four wheel drive, full power. The whole machine has compact structure and flexible operation. The structural parts of the whole machine are optimized, stable and reliable.
● Reliable battery, drive motor and electrical accessory system, advanced AC controller and CANbus data bus technology ensure the durability and long endurance of the equipment.
● The cover of the whole machine can be turned over to facilitate maintenance. The system maintenance items are simple and convenient, saving maintenance time and labor cost. Families can charge by themselves, which is convenient and safe to use.
● The operating device is designed by ergonomics, with comfortable operation and stable driving. The whole machine protection frame provides full safety protection for drivers.
● Pure electric system has the advantages of high efficiency, zero exhaust emission, low noise, environmental protection and energy saving. It is suitable for indoor and outdoor use with lower cost.
● A variety of accessories can be selected to meet the needs of various working conditions such as loading, forking, grass clamping, snow pushing, cleaning, drilling, hoisting and so on.
Model |
Fuel loader |
Electric Loader |
Cost comparison of 200 days per year |
||||
Country |
Diesel price |
Hourly fuel consumption |
Cost of working 8 hours per day |
Electricity price |
Hourly energy consumption |
Cost of working 8 hours per day |
|
Canada |
1.6 C$/L |
5L/h |
64 C$ |
0.06 C$/Kwh |
5Kwh/h |
2.4 C$ |
save 12320 C$ |
U.S.A |
0.66 $/L |
26.4 $ |
0.13 $/Kwh |
5.2 $ |
Save 4240 $ |
||
China |
6.7 RMB/L |
268 RMB |
0.50RMB/Kwh |
20 RMB |
Save 49600 RMB |
Main technical parameter
|
ALS3090EV |
Electric motor model |
PMSM |
Rated power |
5x12kW |
Battery Pack |
53kwh |
Max. Speed (km/h) |
0-13 |
Tire (track) model |
10-16.5 |
Loading Capacity(kg) |
900 |
Bucket capacity(m3) |
0.5 |
Rated flow(L/min) |
62.5 |
hydraulic tank capacity(L) |
70 |
Weight with bucket(kg) |
3300 |
Height at Maximum Extension (mm) |
3980 |
Hinge Pin Height (mm) |
3080 |
Total Height (mm) |
2140 |
Height to bottom of bucket(mm) |
2913 |
Overall length without bucket ( mm ) |
2640 |
overall length with bucket(mm) |
3450 |
Dumping angle at maximum height(° ) |
40 |
Dumping height(mm) |
2380 |
Dumping reach(mm) |
700 |
Rollback at ground position(° ) |
30 |
Rollback fully raised at max height(° ) |
104 |
Wheelbase(mm) |
991 |
Ground clearance(mm) |
185 |
Angle of departure(°) |
20 |
Front turning radius without bucket(mm) |
1168 |
Front turning radius(mm) |
1958 |
Rear tuning radius(mm) |
1630 |
Rear length (mm) |
1108 |
Track width(mm) |
1450 |
Width (mm) |
1850 |
Bucket width (mm) |
1850 |
Company Advantage
• Our products are sold well in many provinces, cities and autonomous regions in China. Moreover, we operate export business in Southeast Asia, the Middle East, Africa and other countries and regions.
• AILISHENG Construction Equipment has a backbone team consisting of technical workers and management personnel of technique, production, quality inspection and others, which has made a strong guarantee for our continuous growth.
• AILISHENG Construction Equipment was established in In the past years, we have continuously improved the R&D capability and have accumulated industry experience. We are dedicated to providing more and better products and services.
• AILISHENG Construction Equipment receives wide recognition from customers and enjoys a good reputation in the industry based on sincere service, professional skills, and innovative service methods.
Would like to know the discount for bulk purchase? Contact AILISHENG Construction Equipment then you will receive free quotation.
