Tracked Robot Chassis Kit Vendor
Product details of the tracked robot chassis kit
Product Overview
What attracts the attention of customers is tracked robot chassis kit of the products. The product has been certified to a number of recognized standards, such as ISO quality standards. The tracked robot chassis kit developed by our company can play a role in various fields. AILISHENG Construction Equipment ensures each step of producing tracked robot chassis kit under the strict quality assurance.
Product Introduction
Compared with general products, the tracked robot chassis kit we produce have the following advantages.
Product features
1. Multi-application scenarios: Due to its versatility, this chassis can be used in various indoor and outdoor environments, including geographic information collection, unmanned driving teaching, inspection applications, agricultural applications, etc.
2. Wire control technology: Through wire control technology, users can operate the vehicle remotely, improving the convenience and safety of operation.
3. Standard communication protocols: Using standard communication protocols makes it possible for the chassis to connect seamlessly with other devices, enhancing system integration.
4. Secondary development: Based on user requirements, secondary development is possible to meet specific application needs.
5. Expansion components and navigation systems: By installing different expansion components and navigation systems, multiple functions can be achieved, such as geographic information collection, unmanned driving teaching, inspection applications, agricultural applications, etc.
6. High intelligence: Through built-in intelligent algorithms, functions such as automatic driving and obstacle avoidance can be achieved, greatly improving work efficiency and safety.
Application scenarios: ALST520 can be widely used in geographic information collection, unmanned driving teaching, inspection applications, agricultural applications, and other scenarios through the use of expansion components and navigation systems.
Main technical parameter
|
|
ALST520 (Standard) |
|
Overall dimensions |
590x490x350mm |
|
Operating weight |
32kg |
|
Carrying capacity |
18kg |
|
Travelling speed |
0 - 3.6km/h |
|
Endurance |
≥10km Straight level road |
|
Drive motor |
servo motor |
|
Battery |
48V/20AH |
|
Operating water depth |
80mm |
|
Maximum gradeability |
30% |
|
Over-height of the obstacle |
70mm |
|
Protect class |
IP55 |
|
Operating temperature |
10℃~50℃ |
|
Drive type |
Four-wheel drive differene steering |
|
Suspension form |
rigid axle suspension |
Company Information
Relying on the insightful observation and mature technology, AILISHENG Construction Equipment is a leading tracked robot chassis kit supplier. AILISHENG Construction Equipment has attained the international level in important technical areas such as R&D, design, manufacturing and construction. The goal of our company is to be a good tracked robot chassis kit supplier.
The products produced are qualified products of high quality. If you are interested in our products, please contact us!
