Company Advantages
· AILISHENG Construction Equipment electric wheel loaders is fabricated using top grade raw materials under the strict supervision of our quality experts.
· AILISHENG Construction Equipment is offering an assortment of quality-approved product.
· As a high-tech company, AILISHENG Construction Equipment runs in a way that integrates research and development, production and service of electric wheel loaders together.
ALS958EV Specifications
Electric Wheel Loaders Parameters
Item |
No. |
Item |
Item |
Main Parameters |
1 |
Rated Load(kg) |
5500 |
2 |
Operating weight(kg) |
18500 |
|
3 |
Bucket capacity(m3) |
3.5 |
|
4 |
Max.traction (KN) |
150-180KN |
|
5 |
Max. breakout force (KN) |
170 |
|
6 |
Max. grade ability(°) |
30 |
|
7 |
Max. dumping height(mm) |
3450 |
|
8 |
Max. dumping distance(mm) |
1200mm |
|
9 |
Dimensions(LxWxH))mm |
8850×3120×3500 |
|
10 |
Min. turning diameter(mm) |
6780 |
|
11 |
Diameter of traverse |
7500 |
|
Hydraulic motor |
12 |
Motor type |
Permanent magnet synchronous motor |
13 |
Motor model |
TZ300-S180 |
|
14 |
Rated power/Peak power(KW) |
80/140 |
|
15 |
Rated speed/Peak speed(r/min) |
850/2300 |
|
16 |
Rated torque/Peak torque(N.M) |
980/1300 |
|
Driving motor |
18 |
Motor type |
Permanent magnet synchronous motor |
19 |
Motor model |
TZ370-S280 |
|
20 |
Rated power/Peak power(KW) |
135/200 |
|
21 |
Rated speed/Peak speed(r/min) |
990/2800 |
|
22 |
Rated torque/Peak torque(N.M) |
1300/2850 |
|
Transmission system |
24 |
Transmission type |
Electro-hydraulic control counter-shaft type |
25 |
Gear number |
F2/R2 |
|
26 |
Speed F1/R1 |
0-12 |
|
27 |
Speed F2/R2 |
0-39 |
|
28 |
Speed F3/R3 |
- |
|
29 |
Speed F4/R4 |
- |
|
Driving system |
30 |
Driving axles type |
Wet-type |
31 |
Axles manufacturor |
Yunyu |
|
32 |
Velocity ratio |
27.53 |
|
33 |
Wheel redction pattern |
Planetary |
|
34 |
Wheelbase(mm) |
3330 |
|
35 |
Wheel track(mm) |
2350 |
|
36 |
Ground clearance(mm) |
480mm |
|
37 |
Tyre spec. |
23.5-25 |
|
38 |
Driving type |
4WD |
|
Hydraulic system |
39 |
Hydraulic pump model & manufacturor |
SGP2112-2090-0016L01Jinan Hydraulic |
40 |
Pump displacement(ml/r) |
112-90-16 |
|
41 |
Valve model and manufacturor |
D32-00A/Gaoyu |
|
42 |
Steering model and manufacturor |
TLF2-E1000C-Zhengjiang |
|
43 |
Working Pressure(Mpa) |
18 |
|
44 |
Boom lifting time(s) |
6.0 |
|
45 |
Boom lowering time(s) |
3.0 |
|
46 |
Dumping time(s) |
1.5 |
|
47 |
Total cycle time(s) |
≦10.5 |
|
Brake system |
48 |
Working brake type |
Hydraulic brake |
49 |
Parking brake type |
Manual clamp type |
|
Battery system |
50 |
System voltage(V) |
24 |
51 |
Battery type |
Water-cooling/heating |
|
52 |
Working voltage(V) |
540 |
|
53 |
Battery capacity(kWh) |
351 |
|
54 |
Battery capacity(Ah) |
579 |
|
55 |
Charging time(h) |
1.5-2(h) |
|
56 |
Charging pile power(kw) |
180-240 |
Company Features
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd has been focusing on the production of electric wheel loaders for many years. We stand out for providing a wide range of innovative products.
· AILISHENG Construction Equipment has great technical strength to manufacture electric wheel loaders. AILISHENG Construction Equipment is performed well for its great quality electric wheel loaders.
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd will never stop pursuing excellence for electric wheel loaders. Contact!
Product Details
Adhering to the concept of 'details and quality make achievement', AILISHENG Construction Equipment works hard on the following details to make the electric wheel loaders more advantageous.
Application of the Product
AILISHENG Construction Equipment's electric wheel loaders is widely applicable in the industry.
AILISHENG Construction Equipment has many years of industrial experience and great production capability. We are able to provide customers with quality and efficient one-stop solutions according to different needs of customers.
Enterprise Advantages
Our company has a high-quality management team, a professional operation team, and a caring service team. All this provides a good guarantee for our production, sales and service.
AILISHENG Construction Equipment insists on providing sincere services to seek common development with customers.
Our company sticks to the business philosophy of 'high quality, high value, high efficiency'. And we adhere to the enterprise spirit of 'pragmatic, innovative, concentrated, united'. Based on that, we develop ourselves by quality products and innovation, and strive to achieve the aim of 'building a first-class brand in the industry'.
AILISHENG Construction Equipment has grown into a modern enterprise with great social influence after years.
AILISHENG Construction Equipment has a sales network of Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders covering the whole country. It also covers many countries and regions, such as Europe, Africa, and America.
