Product details of the wheel loaders for sale
Quick Overview
The appealing design of AILISHENG Construction Equipment wheel loaders for sale allows customers to enjoy the aesthetics. The product meets the international standards in all respects, such as performance, durability, usability, and so on. With high customer satisfaction and awareness, the product is bound to have a wider application prospect in the future.
Product Information
The main differences between AILISHENG Construction Equipment's wheel loaders for sale and similar products are as follows.
ALS966T Specification
|
||
1 |
Length(with bucket on ground) |
8714(mm) |
2 |
Width(to outside of wheels) |
2900(mm) |
3 |
Bucket width |
3048(mm) |
4 |
Height(To the top of the cab) |
3550(mm) |
5 |
Wheel base |
3300(mm) |
6 |
Min. ground clearance |
498(mm) |
|
||
1 |
Rated load |
6000(Kg) |
2 |
Operating weight |
19500KG |
3 |
Rated bucket capacity |
3.7(m3),Optional 2.6-5.0 (m3) |
4 |
Max. dump clearance |
3393(mm) |
5 |
Dump reach |
1365(mm) |
6 |
Min. turning radius(wheel) |
6240(mm) |
|
||
1 |
Model |
ShangChai SC11CB240.1G2B1 |
2 |
Type |
Direct injection. |
3 |
Rated output |
175 (kW) |
5 |
Total exhaust of cylinder |
10.5(L) |
9 |
Rated speed |
2200(r/min) |
10 |
Max. Torque |
912(N.M)@1400 r/min |
|
||
1 |
Model |
ZF4BP210 |
2 |
Type |
3-elements single stage |
3 |
Gear shift position |
4F/3 R |
4 |
Speed(F/R) |
6.6/6.6,11.8/11.8,24.1/24.1,38.6 |
5 |
Max. drawing force |
180kN |
6 |
Size of tire |
23.5-25-20PR |
|
||
1 |
System pressure |
20MPa |
|
||
1 |
System pressure |
16MPa |
|
||
1 |
Type of traveling brake |
Caliper disc brake |
2 |
Air pressure |
6-7.5(kgf/cm2) |
3 |
Type of parking brake |
Manual control cutting-off air brake |
|
||
1 |
Fuel(diesel) |
350(L) |
2 |
Oil for hydraulic system |
245(L) |
Product features
(1) The innovative design of the main frame hinge adopts a "matched" tapered roller bearing structure, which increases the contact area and ensures the reliability of the hinge even under harsh working conditions;
(2) The ZF 4WG200 dual-range system is adopted, with an electric-hydraulic power shift constant-axis gearbox that can achieve forced deceleration. It has simple and safe operation, and high work efficiency;
(3) A small-displacement steering gear and a low-pressure Load Sensing Full Hydraulic Flow Amplification Valve Steering System are used, making the steering wheel easy to operate, flexible, and greatly reducing labor intensity. The steering wheel adopts adjustable devices for more comfortable and convenient operation;
( 4) Based on simulation, emulation, and test verification, an innovatively designed split heat dissipation hydraulic system is developed, which can ensure proper and sufficient heat dissipation for the entire hydraulic system under any working condition, improving the efficiency of the radiator and the reliability of the hydraulic system;
(5)The T series has a large door opening design for the exterior shroud, with both the front inlet and rear outlet of the radiator openable. The new cab upgrade features superior sealing, resulting in significantly lower noise levels than national standards;
(6) The entire vehicle's relays and fuse boxes are centrally arranged, with grease fittings for the working device led to the side of the frame and pressure measuring ports located at the front of the auxiliary box. These user-friendly designs make maintenance and repair easier.
Company Introduction
Xiamen Ailisheng Intelligent Equipment Co.,Ltd, referred to as AILISHENG Construction Equipment, is a company specializing in the production and sales of Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders. 'Customer first, service with heart' is our development concept and 'unity, innovation, pragmatism, progress' is our unswerving pursuit. Our company attaches great importance to the staff training. After training, we have established a team of outstanding talents. They are high in education level and strong in professional ability. AILISHENG Construction Equipment insists on providing customers with one-stop and complete solution from the customer's perspective.
All customers are sincerely welcomed to contact us for consultation!
