AILISHENG Construction Equipment Wheel Loaders for Sale Upply
ALS955T Specification
| l Overall Dimension | |||
| 1 | Length(with bucket on ground)* | 8020(mm) | |
| 2 | Width(to outside of wheels) | 2800(mm) | |
| 3 | Bucket width | 2946(mm) | |
| 4 | Height(To the top of the cab) | 3450(mm) | |
| 5 | Wheel base | 3100(mm) | |
| 6 | Min. ground clearance | 450(mm) | |
| l Technical Specification | |||
| 1 | Rated load | 5000(Kg) | |
| 2 | Operating weight | 16500KG | |
| 3 | Rated bucket capacity | 3.1(m3)，Optional:2.2-4.5 (m3) | |
| 4 | Max. dump clearance | 3136(mm) | |
| 5 | Dump reach | 1171(mm) | |
| 6 | Min. turning radius(wheel) | 5970(mm) | |
| l Diesel engine | |||
| 1 | Model | WeiChai | WeiChai |
| WP10G220E343 | WD10G220E23 | ||
| 2 | Type | Electronic fuel injection | Direct injection. |
| 3 | Emission level | T3 | T2 |
| 4 | Rated output | 162KW | 162 (kW) |
| 5 | Displacement | 9.726(L) | |
| 6 | Rated speed | 2000 | 2000(r/min) |
| 7 | Max. Torque | 980(N.M) | 900(N.M)@1400 r/min |
| l Transmission System | |||
| 1 | Model | HANGHZOU ADVANCE ZL50D-038 | |
| 2 | Type | 4-elements.single stage | |
| 3 | Gear shift position | 2F/1R | |
| 4 | Speed（F/R） | 11.7/15.9，40.3 | |
| 5 | Max. drawing force | 170kN | |
| 6 | Size of tire | 23.5-25-16PR | |
| l Working Hydraulic System | |||
| 1 | System pressure | 18MPa | |
| l Steering System | |||
| 1 | System pressure | 16MPa | |
| l Brake System | |||
| 1 | Type of traveling brake | Caliper disc brake | |
| 2 | Air pressure | 6-7.5(kgf/cm2) | |
| 3 | Type of parking brake | Clamp brake | |
| l Oil Capacity | |||
| 1 | Fuel(diesel) | 280(L) | |
| 2 | Engine lubricating oil | 24(L) | |
| 3 | Oil for converter and gear box | 45(L) | |
| 4 | Oil for hydraulic system | 240（L) | |
| 5 | Oil for driving axles（F/R） | 18/18(L) | |
Performance Features
Performance Features:
（2）The optimized Z-bar loader linkage is offered to provide higher lifting speed, with unloading height of up to 3050mm and breakout force of 160KN. The high efficiency of the wheel loader reflects on quick reaction time and short loading cycle. The design of seal pin provides excellent sealing and lubricant retention, guaranteeing the effect of the lubrication system.
（3）The wheel loader is equipped with high-power WEICHAI engine that complies with the Euro II emission standard. The reasonable matching of power significantly improves traction and breakout force, shortens the work cycle and improves energy efficiency.
（4）The wheel loader features Hangzhou Advance ZL50 planetary gearbox and dual-turbine torque converter, both of which can be easily found in all markets. The gearbox has 2 forward gears and 1 reverse gear, and the speed at first gear is 30% faster than that of other gears on the market, that’s why our wheel loader works particularly well in loading and transporting loose materials.
（5）AILISHENG's independently developed drive axle is a large-modulus transmission component with ability to work under overload conditions for long time yet not shortening its service life. The performance of the drive axle has been approved by severe working conditions, and the reliability of which is particularly appreciated by our customers worldwide. The front and rear drive axle housings and wheel hub reducer are designed with a split structure, which assists users in the reduction of maintenance costs.
（6）The hydraulic oil tank with vacuum device makes it convenient to repair and maintain the hydraulic system, and ensures the hydraulic oil in the system will never be mixed with other chemical substances, prolonging the service life of hydraulic system. The hydraulic oil tank is placed at the rear of the cab, enabling a more space for accessing the transmission system so that the daily maintenance of the transmission system can be easily performed.
Company Advantages
· AILISHENG Construction Equipment wheel loaders for sale features reasonable structure and appealing design.
· Its quality testing is strictly conducted by a professional QC team.
· The product has a large market share due to the strong sales network.
Company Features
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd is known for its outstanding capacity for manufacturing wheel loaders for sale. We are accepted by many customers in the world.
· We have been awarded the honor of "Name Brand of China", "Advanced Export Brand", and our logo is rated with "Famous Trademark". This demonstrates our ability and credibility in the wheel loaders for sale industry.
· The focus of AILISHENG Construction Equipment brand is to keep optimizing its service. Inquire now!
Application of the Product
Our wheel loaders for sale is widely used in multiple industries and fields.
With a focus on Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders, AILISHENG Construction Equipment is dedicated to providing reasonable solutions for customers.
