Mini Graders for Sale Wholesale - AILISHENG Construction Equipment
Company Advantages
· Rational construction design makes mini graders for sale to be operated better and more smoothly.
· This product conforms to the international market strict quality standard.
· The product meets customer expectations and is now popular in the industry with broad market prospects.
Excellent Performance
· Sing-handle electro-hydraulic controlled power-shift T/M, 6forward &3reverse shifts makes operation easy and convenient
· Hydraulic lock, auto lock/unlock NO-SPIN（Optional） differential ensures stability and powerful traction
· Ideal axle load allocation provides excellent stability while cutting hard surface
· Serviceable, efficient hydraulic system enables every part to be fully used.
· Box-typed frame and advanced T/M enable it to complete heavy-duty work.
· A wide working range is accomplished through flexible blade suspension system and articulated frame.
Specifications
| Overall Dimension ALS717H | ||||||||||||
| 1 | Length | 8820mm | ||||||||||
| 2 | Width | 2600mm | ||||||||||
| 3 | Height(To the top of the cab) | 3420mm | ||||||||||
| 4 | Wheel base | 6100mm | ||||||||||
| 5 | Tread | 2120(mm) | ||||||||||
| 6 | Min. turning radius | 7.3（m） | ||||||||||
| Main Technical Specification | ||||||||||||
| 1 | Operating weight | 14500kg | ||||||||||
| 2 | Blade length | 3658mm | ||||||||||
| 3 | Blade height | 580mm | ||||||||||
| 4 | Shovel Blade thickness | 20mm | ||||||||||
| 5 | Max. lift above ground | 450mm | ||||||||||
| 6 | Max. grading depth | 535mm | ||||||||||
| 7 | Max. shoulder reach outside rear tire | 2000mm | ||||||||||
| 8 | Traveling speed(Km/h)，6 forward and 3 reverse | |||||||||||
| (1) forward | 6.5/11.4/14.6/24.8/30/49.2 | |||||||||||
| (2) reverse | 6.5/14.6/30 | |||||||||||
| Diesel engine | ||||||||||||
| 1 | Model | Cummins 6BTA5.9-C180 | ||||||||||
| 2 | Type | Direct injection. Turbocharged. Water cooling | ||||||||||
| 3 | Rated output | 132kW | ||||||||||
| 4 | Rated speed | 2200(r/min) | ||||||||||
| 5 | Max. Torque | 750(N.m) at 1300r/min | ||||||||||
| Transmission case | ||||||||||||
| 1 | Model | 6WG180 (ZF technology) | ||||||||||
| 2 | Type | power shift, single-shift lever, natural-shift lock device | ||||||||||
| 3 | Gear shift position | 6 Forward and 3 reverse gears | ||||||||||
| Axle and Tire | ||||||||||||
| 1 | Max. drawing force | 74.6KN（f=0.75） | ||||||||||
| 2 | Size of tire | 17.5-25-12PR(standard) | ||||||||||
| 13.00-24-12PR(optional) | ||||||||||||
| Working Device Hydraulic System | ||||||||||||
| 1 | System pressure | 17.5MPa | ||||||||||
| Steering System | ||||||||||||
| 1 | Type | Fore Tires deflexion | ||||||||||
| 2 | System pressure | 16MPa | ||||||||||
Company Features
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd pays high attention to talents nurture and many elites together to produce best mini graders for sale.
· Over the years, we have gained a new revenue potential by making our business go global. We have expanded the overseas mini graders for sale market in America, Australia, Germany, and so on. Our company has beefed up distribution in the international mini graders for sale markets, and this strategy has paid off well. Currently, we have the number of customers that is twice than last year.
· Reputation and good credit are the eternal goals of Xiamen Ailisheng Intelligent Equipment Co.,Ltd. Please contact.
Application of the Product
AILISHENG Construction Equipment's mini graders for sale is widely used in the industry.
AILISHENG Construction Equipment always pays attention to customers. According customers' actual needs, we could customize comprehensive and professional solutions for them.
Product Comparison
Compared with other similar products in the market, AILISHENG Construction Equipment's mini graders for sale is provided with the following outstanding advantages.
Enterprise Advantages
Our company gathers industry elites based on our strength. Therefore, we have built a team of professionals with both ability and integrity.
AILISHENG Construction Equipment has a comprehensive service system covering from pre-sales to after-sales. We are able to provide one-stop and thoughtful services for consumers.
Based on the integrity management, our company intends to be aspirant and positive to create mutual benefit and we also pursue the core value of 'customer-centered, technology-led, innovation-driven'. In order to better play synergistic effect, we cooperate with outstanding peers with an open attitude and achieve complementary advantages. All that would enhance the influence of the corporate brand and promote the healthy and sustainable development of our company.
Since the establishment in our company has been devoted to continuous development for years. Now, we become a member of the industry leaders.
AILISHENG Construction Equipment's Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders are not only sold well in China but also exported to countries and regions such as
