Latest 1 Ton Excavator Manufacturer
Product details of the 1 ton excavator
Quick Detail
AILISHENG Construction Equipment 1 ton excavator is manufactured from a well-equipped workshop and manufactured by using the state-of-the-art technology. The product is excellent in quality, reliability, and performance. The superb quality of 1 ton excavator in Xiamen Ailisheng Intelligent Equipment Co.,Ltd is widely known by customers.
Product Information
With a focus on product quality, AILISHENG Construction Equipment strives for quality excellence in the production of 1 ton excavator.
Products Features
Electric Wheel Loaders Parameters
|
Type |
|
ALS60.9 |
|
Operating weight |
T |
6.05 |
|
Bucket capacity(SAE) |
m3 |
0.22-0.28 |
|
Engine model |
|
Yanmar 4TNV94L-BVTY2C |
|
Power |
kw/r/min |
36.2/2100 |
|
Volume of fuel tank |
L |
100 |
|
Travel speed (High/Low) |
km/h |
4.2/2.2 |
|
Swing speed |
r/min |
9.5 |
|
Gradeability |
° |
30 |
|
Digging force of bucket |
KN |
38.5 |
|
Digging force of stick |
KN |
24.3 |
|
Specific pressure of ground contact |
Kpa |
36.1 |
|
Max. Traction |
kN |
55 |
|
Type of hydraulic pump |
|
HP5V76 |
|
Maximum flow |
L/min |
160 |
|
Working pressure |
Mpa |
32 |
|
Volume of hydraulic fluid tank |
L |
80 |
|
A-Overall length |
mm |
5960 |
|
B-Overall Width |
mm |
1960 |
|
C-Overall height(tope of boom) |
mm |
1995 |
|
D-Overall height(tope of cab) |
mm |
2690 |
|
E-Gap from counterweight to ground |
mm |
700 |
|
F-Min ground clearance |
mm |
360 |
|
G-Tail swing radius |
mm |
1700 |
|
H-Length of track on ground |
mm |
2000 |
|
J-Track length |
mm |
2560 |
|
K-Gauge |
mm |
1560 |
|
L-Width of track |
mm |
1960 |
|
M-Width of track shoe |
mm |
400 |
|
N-Width of turning table |
mm |
1906 |
|
O-Max. digging height |
mm |
5750 |
|
P-Max. dumping height |
mm |
3980 |
|
Q-Max. digging depth |
mm |
3860 |
|
R-Max. vertical wall digging depth |
mm |
3040 |
|
Max. digging depth at 2.5m plane |
mm |
3440 |
|
T-Max. digging distance |
mm |
6170 |
|
U-Max. digging distance at plane |
mm |
6045 |
|
Min. swing radius |
mm |
2380 |
|
Max height at min swing radius |
mm |
4395 |
|
Distance from center of swing to rear end |
mm |
1700 |
|
Y-Thickness of track grouses |
mm |
14 |
|
Length of stick |
mm |
1630 |
|
Length of boom |
mm |
3000 |
Company Advantages
Xiamen Ailisheng Intelligent Equipment Co.,Ltd is located in xia men and we are a company mainly producing Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders. Our company adheres to the enterprise tenet of 'work hard to benefit the country', and abides by the management philosophy of 'people-oriented, mutual promotion and common development'. We strive to provide high-quality products and create a century-old brand to. Our company has professional talents who are in charge of the R&D, production and sales of our products. AILISHENG Construction Equipment has been engaged in the production of Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders for many years and has accumulated rich industry experience. Based on that, we could provide comprehensive and excellent solutions according to actual situations and the needs of different customers.
We are committed to guaranteeing the product quality and after-sales service. Welcome to contact us for cooperation!
