Product details of the digger manufacturers


Quick Overview

All raw materials of AILISHENG Construction Equipment digger manufacturers are subjected to intense controls. This product has good durability and is suitable for long-term use and storage. The digger manufacturers produced by AILISHENG Construction Equipment is widely used in industry. The strength of the staff team in Xiamen Ailisheng Intelligent Equipment Co.,Ltd is continuously strengthened.


Product Information

AILISHENG Construction Equipment's digger manufacturers is processed based on advanced technology. It has excellent performances in the following details.

High-efficiency Kawasaki hydraulic system

The overall performance of the hydraulic system is reasonably matched with the output power of the engine, which significantly reduces energy loss.

图片1 (4)
图片1 (4)
图片2 (3)

High reliability Cummins engine

Using the well-proven Cummins 6CTAA8.3-C260-II engine, it has abundant power and good durability and is suitable for fuel in general areas with high fuel economy. Reduce fuel consumption through advanced control technologies in hydraulic and Cummins engine aspects.

High efficiency working perfomance

The potent power output and Ailisheng's unique intelligent control system and intelligent power control technology ensure efficient operation and reduce fuel consumption.

ALS300

Ultra-long life

Finite element stress analysis software and MT and UT dual flaw detection guarantees are used to improve the strength of structural parts and covering parts.

Strengthened boom

The shape of the boom has been optimized by finite elements design, allowing the loads to be better distributed throughout the structure. This combined with increased material thickness means improved durability and reliability by limiting element fatigue.

图片3 (3)
图片4 (3)

Strengthened Arm

In the arm assembly greater strength has been gained by using cast elements and reinforcement around the bosses to give it an increased lifetime.

X-chassis

The X-chassis frame section has been designed using finite element and 3-dimensional computer simulation, to ensure greater durability and optimum structural integrity. The swing gear is solid and stable.

图片5 (2)
图片6 (2)

D-type frame

The D-type frame and chassis frame add strength and minimize distortion due to shocks.

Bucket

Highly wear-resistant materials are used for the most susceptible elements such as the blades, teeth, rear and lateral reinforcement plates and corners of the bucket.

图片7 (2)

Luxury cab

Adhering to Ailisheng's driver-centered design concept, with comfortable operation, wide field of vision and low noise. It has an air-conditioning system that meets the operation's needs and a multi-functional LCD instrument panel to improve the comfort and convenience of the operation.

The main frame and boom are equipped with LED work headlights as standard

Significantly improving the driver's night work vision and improving night work efficiency and safety.

ALS300 (3)
图片8 (2)

Maintainability

Short maintenance operations at long intervals increase the availability of the equipment on site. Ailisheng has developed the Ailisheng 300.8 with a view to high profitability for the user.

Access to the various radiators is very easy, making cleaning easier. Access to the various parts of the engine is from the top and via side panels.

Engine oil filter

The engine oil filter offers a high level of filtration allowing the oil change interval to be increased to 500 hours. It is easy to access and is positioned to avoid contaminating the surrounding environment.

ALS300 (2)
图片9 (2)

Air cleaner

The large capacity forced air cleaner removes over 99% of airborne particles, reducing

the risk of engine contamination and making the cleaning and cartridge change intervals

greater.

Fuel filter

High efficiency fuel filtration is attained by the use of multiple filters, including a fuel pre-filter fitted with a water separator that removes most moisture from the fuel.

图片10 (2)
ALS300 (4)

Hydraulic oil return filter

The protection of the hydraulic system is made more effective by the use of glass fibre filter

technology in the main oil return filter. This means that with more than 99,5% of foreign particles filtered out, the oil change interval is increased.

Service

Our commitment to total customer satisfaction extends worldwide. To keep your machine and business up and running with Ailisheng uptime services that are proven to cut repair costs and unplanned downtime. Ailisheng always takes customer needs as the starting point and provides customers with a full range of services, including maintenance, repair, accessories, and value-added care.

Application range: mining, general engineering, municipal engineering, road engineering.

ALS300

Type



ALS300.8

Operating weight

T

30

Bucket capacity(SAE)

m3

1.4

Engine model



 6CTAA8.3-C260-II

Power

kw/r/min

194/2000

Volume of fuel tank

L

595

Travel speed (High/Low)

km/h

5.9/3.4

Swing speed

r/min

9.4

Gradeability

°

35

Digging force of bucket

KN

179

Digging force of stick

KN

145

Specific pressure of ground contact

Kpa

65.1

Max. Traction

kN

279.8

Type of hydraulic pump



K5V160DT

Maximum flow

L/min

265*2+30

Working pressure

Mpa

34.3

Volume of hydraulic fluid tank

L

310

A-Overall length

mm

10882

B-Overall Width

mm

3190

C-Overall height(tope of boom)

mm

3310

D-Overall height(tope of cab)

mm

3280

E-Gap from counterweight to ground

mm

1210

F-Min ground clearance

mm

523

G-Tail swing radius

mm

3418

H-Length of track on ground

mm

4030

J-Track length

mm

4957

K-Gauge

mm

2590

L-Width of track

mm

3190

M-Width of track shoe

mm

600

N-Width of turning table

mm

2995

O-Max. digging height

mm

9960

P-Max. dumping height

mm

6983

Q-Max. digging depth

mm

6993

R-Max. vertical wall digging depth

mm

5460

Max. digging depth at 2.5m plane

mm

6813

T-Max. digging distance

mm

10728

U-Max. digging distance at plane

mm

10530

Min. swing radius

mm

4280

Max height at min swing radius

mm

8387

Distance from center of swing to rear end

mm

3418

Y-Thickness of track grouses

mm

26



mm

2274



mm

5940



mm



Length of stick

mm

3050

Length of boom

mm

6250
