Best Soil Vibratory Compactors Company
Product details of the soil vibratory compactors
Product Introduction
AILISHENG Construction Equipment soil vibratory compactors is fabricated combining with the simple and modern design concept. This product has good performance and long service life. Professional packing ensures that soil vibratory compactors does not get damaged during transportation.
Performance
● "Equipped with Cummins engine, enjoying a stable and reliable performance.
● "Equipped with the closed hydraulic driving system consisting of plunger pump and plunger motor from REXROTH or SAUER, enjoying high working pressure and long service life.
● Applying the front and rear wheels dual-drive mode, thus providing proper driving performance.
● Most of mass distributed on the vibrating drum i.e. more than 56% of the total weight, producing large exciting force, proper compacting performance and high working efficiency as a result.
● The spacious and quiet cab provides excellent all-around visibility and features thermal insulation, vibration reduction.
● The machine is also equipped with an optional compactibility measuring instrument, according to users’ requirement. "
Specifications
|
Description |
Unit |
ALS612H |
|
|
Operating Weight |
kg |
12100 |
|
|
Drum Weight |
kg |
7100 |
|
|
Driving Wheel(D×W) |
mm |
Φ1550X2130 |
|
|
Travel Speed |
Ⅰ |
km/h |
0～4.3 |
|
|
Ⅱ |
km/h |
0～6.4 |
|
|
Ⅲ |
km/h |
0～9.2 |
|
|
Ⅳ |
km/h |
/ |
|
Max. Gradeability |
% |
50 |
|
|
Vibration Frequency |
Hz |
30 |
|
|
Amplitude (H/L) |
mm |
1.7/0.85 |
|
|
Centrifugal Force(H/L) |
KN |
247/127 |
|
|
Min. Turning Radius |
mm |
6300 |
|
|
Engine |
Brand |
|
Cummins |
|
|
Model |
|
6BT5.9-C150 |
|
|
Rated power |
kW |
112 |
|
|
Rated speed |
rpm |
2400 |
|
Tire spec. |
|
23.1-26-12PR |
|
|
Tire pressure |
MPa |
0.14-0.17 |
|
|
Steering hydraulic system |
Maximum steering angle |
° |
35 |
|
|
Maximum swinging angle |
° |
9 |
|
System voltage |
|
DC 24V |
|
|
Overall Dimension(L×W×H) |
mm |
5717×2270×3200 |
|
Company Advantage
• AILISHENG Construction Equipment owns high-quality products and practical marketing strategies. Besides, we also provide sincere and excellent services and create brilliance with our customers.
• Established in AILISHENG Construction Equipment has been continuously launching competitive products during the rapid development for years. Now we become a leader in the industry.
• Gathered multi traffic lines, the location of AILISHENG Construction Equipment provides convenience for transportation. In this way, we ensure the efficient transportation of different products.
• Our sales terminals form a sales network throughout the domestic and international markets. It helps us to constantly set a good sales record at home and abroad.
AILISHENG Construction Equipment's leatherware is of reliable quality and affordable price. If you want to know more about our products or services, please contact us! Contact us now and you will have a chance to get a free sample.
