Best Mini Skidsteer Mini Skidsteer Company
Product details of the mini skidsteer
Product Information
Made of well-selected materials and manufactured based on the lean production method, AILISHENG Construction Equipment mini skidsteer presents the finest workmanship in the industry. The product is quality-assured as we always keep 'quality first' firmly in mind. When there are options, Xiamen Ailisheng Intelligent Equipment Co.,Ltd will thoroughly describe each available alternative for customers.
Product features
- Delivering unmatched performance, versatility, and ease of operation, the Ailisheng Skid Steer Loader is ideal for small confined areas, such as constructions sites, factory facilities, workshops, warehouses, docks, decks, ship cabins as well as other key sectors.
- Skid steer loader can attach various attachments to perform shoveling, stacking, lifting, digging, boring, breaking,grabbing, pushing, scarification, trenching, compacting, road cleaning, and many other operations which are provided to increase your flexibility, enabling you to handle many jobs with just the one machine.
- Using of simulation technology to learn the mission data at travelling and working conditions helped optimizing power and fuel efficiency.
-Compact structure, maneuverable movement suitable for narrow Space operation.
-Open cabin with mechanical control system.
-Double accelerograph control.
-Hydraulic brake.
Main Parameters
|
|
ALS3100 |
|
Engine Brand |
Xinchai |
|
Engine model |
498T |
|
Bore x stroke (mm) |
98X105 |
|
Rated power (Kw) |
55 |
|
Rated speed(rpm) |
2450 |
|
Number of cylinders |
4 |
|
Max. torque (N.m) |
245 |
|
Displacement (L) |
3.16 |
|
Max. Speed (km/h) |
12 |
|
Tire (track) model |
12-16.5 |
|
Loading Capacity (kg) |
950 |
|
Lifting Type |
Arc-Shaped Lifting |
|
Bucket capacity(m3) |
0.5 |
|
Rated flow(L/min) |
75 |
|
tank capacity(L) |
80 |
|
Weight with bucket(kg) |
3350 |
|
Dimension |
|
|
Height at Maximum Extension(mm) |
4000 |
|
Hinge Pin Height (mm) |
3100 |
|
Total Height (mm) |
2160 |
|
Height to bottom of bucket(mm) |
2933 |
|
Overall length without bucket ( mm ) |
2750 |
|
overall length with bucket(mm) |
3490 |
|
Dumping angle at maximum height(° ) |
40 |
|
Dumping height(mm) |
2400 |
|
Dumping reach(mm) |
750 |
|
Rollback at ground position(° ) |
30 |
|
Rollback fully raised at max. height(° ) |
104 |
|
Wheelbase(mm) |
1085 |
|
Ground clearance(mm) |
205 |
|
Angle of departure(°) |
20 |
|
Front turning radius without bucket(mm) |
1204 |
|
Front turning radius(mm) |
2030 |
|
Rear tuning radius(mm) |
1706 |
|
Rear length (mm) |
1082 |
|
Track width(mm) |
1500 |
|
Width (mm) |
1880 |
|
Bucket width (mm) |
1880 |
|
The structure and parameters are subject to change without prior notice due to technical progress. If the sample product is different from the actual product in some way, the actual product shall prevail. |
|
Company Feature
• AILISHENG Construction Equipment was built in After years of experience in innovation, we have developed into a model enterprise with leading technology in the industry.
• AILISHENG Construction Equipment's products are sold to major cities in China and exported to countries and regions such as Asia, Europe, and Africa.
• Our company is located in a beautiful place with outstanding people. And, there is a well-developed transportation network. It is conducive to the purchase and shipment of goods.
Based on the professional production technology, AILISHENG Construction Equipment produces quality Electric Construction Equipment,Excavators,Wheel Loaders,Soil Vibratory Compactors,Landfill Compactors,Skid Steer Loaders,Forklift Trucks,Telescopic Forklift,Dozers,Motor Graders,Backhoe Loaders in large quantity. Our products are safe and eco-friendly, in line with national quality control standard. We guarantee the quality and provide you with a worry-free buying experience.
