Company Advantages
· mini dozer for sale is made up of composite material.
· The quality of this product is guaranteed with international advanced production. .
· AILISHENG Construction Equipment is equipped with very professional customer service team.
It is mainly applied to the push, excavation, backfilling earthwork and other bulk materials operations of roads, railways, mines, airports, etc. It is an indispensable mechanical equipment for national defense engineering, mine construction, urban and rural road construction and water conservancy construction.
Main Features
•A Weichai WD10G178E25 engine which gives you more power and reliability you need. Improved fuel economy over the previous model with strong torque output and low fuel consumption gives you excellent overall fluid efficiency.
•The gearbox uses a planetary gear structure that operates the hydraulic control valve to achieve forward, reverse and various shifts. The structure is planetary gear, multi-plate clutch, hydraulic combined with forced lubrication, which is divided into three forward and three reverse.
•The closed system keeps the tank pressure at a specific value, which can increase the evaporation temperature and heat dissipation efficiency of the cooling water. The fan power comes from the engine, and the forced air supply increases the cooling effect.
•Mainstream 14MPa working hydraulic system,can greatly reduce the failure rate of hydraulic components with overload protection function.
•The use of waterproof connector of the whole vehicle,new relays and injection molding instruments can effectively eliminate the failure of the electrical system. The instrument box integrates air conditioning, electrical appliances and instruments into one, which is more beautiful and luxury.
•The main frame of the full box structure adopts steel plate welded full box type integral structure, which is welded with the rear axle box. It has high impact load bearing capacity and resistance to bending and twisting. High quality weld seam ensures the main frame has a full life cycle.
•The swing type balance beam suspension structure with splayed beam is connected with the frame and traveling system to transmit the working load and impact load to the main frame during working, which effectively improves the stability of small-sized bulldozers under complicated working conditions.
•The standard straight tilt blade features powerful cutting force and the three-shank ripper can be equipped for the ripping of clay and frozen earth, featuring high working efficiency and super-strong penetrating force.
Main Specifications
Model | ALS416 |
Type | Standard Hydraulic Crawler Type |
Model | Weichai WD10G178E25 |
(L)Displacement | 9.726 |
(kw/rpm)Rated power | 131/1850 |
(N.m/rpm)Max.torque | 830/1000-1200 |
Operating weight | 16.4T |
(mm) Dimension(no ripper) | 4990×3440×3110 |
(mm) Min ground clearance | 405 |
(MPa) Ground pressure | 0.067 |
(mm) Track gauge | 1880 |
(m³) Dozing capacity | 4.55 |
(mm) Blade width | 3440 |
(mm) Blade height | 1135 |
(mm) Max drop below ground | 540 |
(mm) Track shoe width | 510 |
(mm) Pitch | 203.2 |
Quantity of track link | 37 |
Quantity of Carrier rollers | 4 |
Quantity of Track rollers | 12(8 Double+4 Single) |
(MPa) Max pressure | 14 |
L/min Discharge | 213 |
KN) Max tractor force | 146 |
Grade ability | 30° |
(Km/h) Forward Speed | F1:0-3.29 |
F2:0-5.82 | |
F3:0-9.63 | |
(Km/h) Rear Speed | R1:0-4.28 |
R2:0-7.59 | |
R3:0-12.53 |
Company Features
· With advanced equipment, Xiamen Ailisheng Intelligent Equipment Co.,Ltd can make sure high quality and high efficiency during manufacturing mini dozer for sale.
· Strong methods and sound quality management system guarantee the quality of mini dozer for sale. Having a complete set of quality management platform, AILISHENG Construction Equipment may fulfill the requirements of different clients. Xiamen Ailisheng Intelligent Equipment Co.,Ltd only provides the finest-quality mini dozer for sale
· In accordance with the principle of prudent operation, Xiamen Ailisheng Intelligent Equipment Co.,Ltd will make no effort to increase its competitiveness. Ask!
Application of the Product
The mini dozer for sale produced by AILISHENG Construction Equipment has a wide range of applications.
With Internet technology, we provide a one-stop solution for practical and effective implementation of related problems encountered in the process of purchasing products.
