Top Small Electric Loader Small Electric Loader Company
Company Advantages
· small electric loader pursues best performance and perfect design.
· This product has been officially certified according to industry quality standards.
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd has obtained certificate of design patent.
Product features
● Four wheel drive, full power. The whole machine has compact structure and flexible operation. The structural parts of the whole machine are optimized, stable and reliable.
● Reliable battery, drive motor and electrical accessory system, advanced AC controller and CANbus data bus technology ensure the durability and long endurance of the equipment.
● The cover of the whole machine can be turned over to facilitate maintenance. The system maintenance items are simple and convenient, saving maintenance time and labor cost. Families can charge by themselves, which is convenient and safe to use.
● The operating device is designed by ergonomics, with comfortable operation and stable driving. The whole machine protection frame provides full safety protection for drivers.
● Pure electric system has the advantages of high efficiency, zero exhaust emission, low noise, environmental protection and energy saving. It is suitable for indoor and outdoor use with lower cost.
● A variety of accessories can be selected to meet the needs of various working conditions such as loading, forking, grass clamping, snow pushing, cleaning, drilling, hoisting and so on.
Main technical parameter
|
ITEM |
ALS350EV |
|
|
Main parameter |
Operating weight |
2650Kg |
|
Rated Load |
700Kg |
|
|
Bucket capacity |
0.5m³ |
|
|
Moving speed |
0-18km/h |
|
|
Moving motor |
Motor type |
Permanent magnet synchronous motor |
|
Rated power of motor |
20kw |
|
|
Motor Duty Rating |
Duty with non-periodic load and speed variations |
|
|
Hydraulic Pump Moto |
Rated power of motor |
10Kw |
|
Motor Duty Rating |
Duty with non-periodic load and speed variations |
|
|
Battery |
Battery Type |
Lithium iron phosphate |
|
Battery Voltage |
144V |
|
|
Battery rated capacity |
155Ah(standard) |
|
|
Battery weight |
260Kg |
|
|
Charging time |
AC220V Charge:3h |
|
|
Operating time with full load |
3.5h |
|
|
Operating time with rated load |
4-5h |
|
|
Intermittent operation time |
5-6h |
|
|
Theoretical lifespan |
25 ℃ 0.5c charge and discharge for 3000 times, and the capacity shall not be less than 80% of the nominal capacity |
|
|
Driving system |
Operating voltage of driving system |
144V |
|
Electrical system |
Voltage of electrical system |
12V |
|
Tripping load with bucket(Refer to ISO8313) |
Tripping load when straight line driving |
1250Kg |
|
Tripping load when full turn |
900Kg |
|
|
Hydraulic drive system |
Displacement |
12 cc |
|
Working pressure |
170bar |
|
|
Hydraulic oil capacity |
30L |
|
|
Tyre |
Specifications |
26Í12-12 AS |
|
Total width |
1104mm |
|
Overall dimension
|
Dimensions |
ALS350EV |
|
A Total length with standard bucket |
4330mm |
|
A′ Transport position vehicle length |
4260mm |
|
Non-enclosed trailer height |
1970mm |
|
B Height to top of cabin |
2330mm |
|
C Total width |
|
|
Narrow tire |
1075mm |
|
Wide tire |
1329mm |
|
D Wheel base |
1550mm |
|
E Minimum ground clearance |
345mm |
|
F Track width |
|
|
Narrow tire |
812mm |
|
Wide tire |
939mm |
|
G Bucket width |
1370mm |
|
H Radius at the outer edge |
2541mm |
|
H′ Max. radius |
3037mm |
|
I Total working height |
3630mm |
|
J Max. height of bucket pivot |
2950mm |
|
K Maximum dumping height |
2190mm |
|
L Dumping reach |
630mm |
|
M Digging depth |
150mm |
|
N Max. inclination angle |
43° |
|
O Backroll angle on the ground |
42° |
|
P Departure angle |
22° |
|
Q Max. dumping angle |
32° |
|
T Total length without bucket |
3550mm |
Company Features
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd holds a leading position in China in terms of small electric loader production.
· Xiamen Ailisheng Intelligent Equipment Co.,Ltd is internationally well-known for its technology strength.
· Aiming at creating more values for customers through high quality small electric loader has been always kept in each AILISHENG Construction Equipment's mind. Ask online!
Application of the Product
small electric loader is one of the main products of AILISHENG Construction Equipment. With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers.
Based on customers' specific situations and needs, AILISHENG Construction Equipment provides comprehensive and reasonable solutions.
Product Comparison
Compared with other products in the industry, small electric loader has more obvious advantages which are reflected in the following aspects.
Enterprise Advantages
Our researchers, technicians and quality inspectors are the powerful guarantee for our continuous development.
AILISHENG Construction Equipment is dedicated to providing quality services to meet the needs of customers.
In accordance with the tenet of 'to survive by unity, to seek market by quality, to develop by credit', our company is willing to form a trading partnership with large and small merchants at home and abroad to seek common development and achieve the goal of double profit.
Since the establishment in our company has gained great growth through the absorption and acceptance of advanced technology and knowledge. Through the continuous breakthrough for years, we have made remarkable achievements in the industry.
AILISHENG Construction Equipment's products have been sold to the domestic market and overseas markets such as Western Europe, Eastern Europe, North America, and South America. The sales scale and quantity rank top in the domestic industry.
